Engine and Drive Train | |
---|---|
Cylinders | 1 |
Strokes | 4-Stroke |
Displacement | 110 ccm |
Bore | 50 mm |
Stroke | 55,6 mm |
Max. Power Output | 7,3 HP |
Rpm at Max. Power Output | 7500 rpm |
Max. Torque | 8,9 Nm |
Rpm at Max. Torque | 3500 rpm |
Compression Ratio | 9 |
Starter | Kick |
Ignition | CDI |
Final Drive | Chain |
Chassis | |
Frame | Steel |
Frame type | Backbone |
Brakes Rear | |
Rear brake | Drum |
Dimensions and Weights | |
Front tyre width | 70 mm |
Front tyre height | 100 % |
Front tyre diameter | 14 inch |
Rear tyre width | 80 mm |
Rear tyre height | 100 % |
Rear tyre diameter | 12 inch |
Length | 1560 mm |
Width | 686 mm |
Height | 912 mm |
Wheelbase | 1064 mm |
Seat Height from | 667 mm |
Kerb Weight | 74 kg |
Fuel Tank Capacity | 5 l |
License | A1 |
All information is supplied without guarantee. Errors and clerical errors reserved.
