Engine and Drive Train | |
---|---|
Cylinders | 1 |
Strokes | 4-Stroke |
Valves per cylinder | 2 |
Cooling | Air |
Displacement | 49 ccm |
Bore | 39 mm |
Stroke | 41,1 mm |
Max. Power Output | 3 HP |
Rpm at Max. Power Output | 8500 rpm |
Max. Torque | 3,43 Nm |
Rpm at Max. Torque | 3500 rpm |
Compression Ratio | 10 |
Starter | Kick |
Ignition | CDI |
Final Drive | Chain |
Transmission Type | Automatic, Semi-automatic |
Number of gears | 3 |
Chassis | |
Frame | Steel |
Frame type | Backbone |
Suspension Front | |
Front suspension | Upside-Down telescopic fork |
Brakes Rear | |
Rear brake | Drum |
Dimensions and Weights | |
Length | 1302 mm |
Width | 581 mm |
Height | 774 mm |
Wheelbase | 911 mm |
Seat Height from | 548 mm |
Kerb Weight | 50 kg |
Fuel Tank Capacity | 2,6 l |
License | AM |
All information is supplied without guarantee. Errors and clerical errors reserved.
